DVB-T2/ ISDB-T/C USB Dongle For Android

General Features

• DVB-T/T2/C demodulator AVL6782 + Tuner Rafeal R850

• Media stream and instructions communicate with USB 2.0

• Work with various Android OTT, TV and smart phone.

• DVB Player, Android App, work with the RCU of the Android OTT or TV, and updated by google play.

• Compatible with Android 9 and above versions and rapidly support latest version if updated.

• Support decrambling

• The same hardware can be designed into a Android OTT box or TV main board.

• Support HEVC H.265 & 4K

Size

Dongle Length x Width x Height  93 mm x 36 mm x 17 mm

Interfaces

• Single RF tuner with IEC connector

• USB 2.0 with cable

Power Supply

• Voltage 5.0V from USB interface

Function with App

• Scan with full scan, manual scan, and play DVB-T/T2 channels

• Play and PVR in the same frequency.

• Support EPG and Timer

• Various types of channel list and channel editing

• Easy UI, accessed with common buttons(Menu,OK, Back and Left/Right/Up/Down) in RCU, or accessed with touch screen and mouse.

• Support hardware and software A/V decoder

• Support EMU

• Easy and Fast to update the App
